Single,Two Speed,23206 PSI,Lightweight Hydraulic Hand Pump

5out of5based on2 reviews | Write a review

Model Number:SPS16-1|SPS16-3

Pump Type:Double Speed

Used with Cylinder:Single-Acting

Usable Oil Capacity(cm³):1440/3240

Max.Operating Pressure: 1600

Pressure Rating 1st Stage: 15bar/217.5 psi

Pressure Rating 2st Stage:1600bar/23206 psi

Output Oil Volume Each Stroke 1st Stage (cm³)32

Output Oil Volume Each Stroke 2st Stage (cm³)2.5

Weight:6.3/10(kg)

Model Number:SPS16-1|SPS16-3

Pump Type:Double Speed

Used with Cylinder:Single-Acting

Usable Oil Capacity(cm³):1440/3240

Max.Operating Pressure: 1600

Pressure Rating 1st Stage: 15bar/217.5 psi

Pressure Rating 2st Stage:1600bar/23206 psi

Output Oil Volume Each Stroke 1st Stage (cm³)32

Output Oil Volume Each Stroke 2st Stage (cm³)2.5

Weight:6.3/10(kg)


1:Made of aluminum titanium alloy,light weight, high strength,corrosion

and impact resistance to various harsh environments.

2: Better protability with the handle.

3:Two speed operation,build-in high and low pressure automatic switch valve.

Providing greater flow at low pressure to save operation time and  increase the work efficiency.

4: Build-in safety valve inside to provides safe dual-protection.

5: Pressure regulating valve can readjust working pressure.

6:The unique press rod mechanism is more easy to operate.


Model  NumberPump TypeUsed with CylinderUsable Oil CapacityPressure Rating
       (bar)
Output Oil Volume Each Stroke
       (cm3)
Handle ForceOver Dimension (mm)Output AdapterWeight
ABC
(cm3)1st Stage2st Stage1st Stage2st Stage(N)Kg
SPS16-1Double SpeedSingle-Acting1440151600322.5375577120170G1/4"6.3
SPS16-3324058220017010


Hydraulic-Lightweight-Hand-Pumps -56.webp


Pressure Display Unit (Optional)

Prevent overloading, pressure gauge adaptor + pressure gauge to achieve pressure display or one pump two top function.

For more information on pressure gauges  adaptor  and pressure gauges, see the section "hydraulic components".


Hydraulic-Lightweight-Hand-Pumps -30.webp


Hydraulic-Lightweight-Hand-Pumps -57.jpg



applications

Suitable for nut splitters, flange spreaders, single  acting  Hydraulic Cylinders and other hydraulic tools.


Tip:

SAIVS Industrial provides top-quality Single,Two Speed,23206 PSI,Lightweight Hydraulic Hand Pump for hydraulic systems in various industries. Our products are designed for performance, reliability, and durability. We offer a wide range of products to suit your needs, including upgrades, maintenance, and repairs.

PROVIDING EXCELLENT SOLUTIONS BY SAIVS™


Speak to one of our experts today to learn more about our Single,Two Speed,23206 PSI,Lightweight Hydraulic Hand Pump products solutions.


Request a Quote

Tags: Lightweight Hydraulic Hand Pump 23206 PSI Lightweight Hydraulic Hand Pump Two Speed Single Speed
  • Q: Are you trading company or manufacturer?
  • A: We are factory with more than 20 years experience.
  • Q: How long for delivery?
  • A: Generally it is 15-30days as we are customized service we confirm with customer when place order.
  • Q: What is the MOQ?
  • A: It depends on what you are buying. Normally, our minimum order is one 20' full container and LCL container (less than a container load) can be acceptable.
  • Q: Can you customize my products?
  • A: Yes, we can customized products with your design drawings like DWG, DXF, DXW, IGES, STEP, PDF etc.
  • Q: What is your terms of payment?
  • A: 30% T/T in advance, balance before shipment, or as per discussion.
  • Q: What about your quality control?
  • A: 1.Checking the raw material after they reach our factory(IQC) 2. Checking the details before the production line operated.3.Have full inspection and routing inspection during mass production(IPQC) 3.Checking the goods after they are finished(FQC). 4.Checking the goods after they are finished(QC). 5.100% inspection and delivery before shipment
  • Q:What if there is a problem with the purchased product?
  • A:If any quality problem happens please take some photos and videos to show the exact problem, then our engineer will judge and give a solution.
  • Q:Do you provide OEM service?
  • A:Yes, we provide OEM service. We will produce products that meet your requirements according to the logo, product parameters and dimensions you provide. Please contact us for more details.
  • Q:Can I be an agent for SAIVS products?
  • A:Of course, please contact us for more details.
